Led Strip
SJ-100144-APA102C SJ-100144-APA102C SJ-100144-APA102C SJ-100144-APA102C
■. It can be used for KTV decorative lights.
■. It can be used for home lighting decoration.
■. It  can be used to create LED advertising logo.
■. It can be used for stage lighting decoration.
■. It can be used for entertainment lighting decoration.
■. It can be used for shopping mall counter lighting.


Addressable apa 102 led 144 strip RGB light


1. Control IC APA102C/SK9822 inserted in 5050 RGB diode , individually addressable control . supporting numerous color-change effects .
2. It comes in 1 meters per reel with a 4Pin JST SM connector on both end and separated Power / Ground Wires . Customized length is workable .
3. Flexible PCB material . Each LED/Pixel can be cut , there is cut lines every 6.9mm.
4. 144LEDs/M . 5V low voltage inputted , don’t over 6V , otherwise you will destroy the entire strip .
5. 12mm width PCB , 0.25mm thickness with 3M tape back side for non-weatherproof version . 14.5mm width , 4mm thickness with silicon tube for waterproof version .
6. Date Pin and Clock Pin for signal transfer.
7. This APA102/SK9822 Strip also can be produced in single white color.
8. We also have 30 /60 / 72/92 leds per meter .


P/N Size/mm LED Type Pixel/m Luminous Angle Voltage Wattage/m IP Rate
W12 * L0.25mm
APA102/9822-smd5050 144 Pixel/m 1008 160° DC5v 34.5w IP20/65


Project case

back lights, cabinet lights, edge light, architectural lights for corridor, canopy, archway, lights for path
and contour marking; etc.They can be a good choice for lights for hotels, restaurants, night clubs, coffee / wine bars, shopping malls,
various shops, cinemas, beauty centers, office fronts, even lights for household kitchens or living rooms, etc.
