26mm
Event decoration lighting UCS1903 digital 12 volt rgb pixel led string light Event decoration lighting UCS1903 digital 12 volt rgb pixel led string light Event decoration lighting UCS1903 digital 12 volt rgb pixel led string light Event decoration lighting UCS1903 digital 12 volt rgb pixel led string light Event decoration lighting UCS1903 digital 12 volt rgb pixel led string light
Event decoration lighting UCS1903 digital 12 volt rgb pixel led string light
Part NO SJ-3D-UCS1903
Lighting Source 2PCS SMD3535 RGB LED
Beam Angel 360 degree
Operate Voltage DC12V
Consumption Watt/M 0.48Watt (max)
Diameter (mm) 26 mm
Pixel pitch 10cm, can be customized
IC chip UCS1903 full color
Quantity 20 pcs /string
Waterproof Grade IP30
Lifetime 50000H
Working temperature -20℃-60℃
Storage temperature -30℃-80℃


SJ-3D-Ball

Features

1-Digital led pixel string for indoor application.
2-Each pixel individually control.
3-20pcs per chain with 8 cm space (standard length) but it‘s could customization.
4-There is 2pcs super bright smd3535 RGB LED inside of each lamp.
5-The connectors are waterproof 4pin female/male connector, the Male with Pin is Input.
6-The whole string light is non-waterproof.
7. Controller System:SD controller , DMX controller , Artnet and so on

Parameter
P/N Diameter/mm LED Type IC Type Luminous Angle Voltage Wattage/PCS IP Rate
SJ-3D-Ball 26mm DMX / UCS1903 AU 112 360° AC12/24V 0.48W IP67
